KD Series

DIGITAL AMPLIFIER

KDseries

The K2004 and K8004 series are 4CH professional digital power amplifiers with excellent sound quality and durability, designed for use in touring or installing to get the most performance out of your speakers. Analog 4-channel input, Dante™ digital audio network input, and built-in high-performance digital signal processing for optimal speaker tuning to achieve sound quality for your space.

K2004 Downloads

Description

· High Quality CLASS-D Professional Amplifier

· 4CH Dante™ Digital Audio Input

· Built-in DSP

· Easy Control of Equipment Through Front Panel With OLED and PC GUI

· Easy One-Touch Front Dust Filter Cleaning

· Simultaneous Control of Multiple Amplifiers Via PC GUI

· Up to 340 ms Delay Time Adjustable

· Frequency Band Adjustment Using HPF and LPF

· Unlimited Preset Creation For Environment-Optimization

TECHNICAL SPECIFICATIONS

8Ω / 4Ω / 2Ω STEREO MODE (-20ms Burst)	300W / 500W / 800W	8Ω / 4Ω BRIDGED MONO MODE (-20ms Burst)	1000W / 1600W(800W)
Input Sensitivity	+4dBu	Gain (STEREO & MONO / BRIDGE)	32dB / 38dB
S/N	92dB 이상	THD (1/3W Rated Power)	0.5% 이하
Frequency Response (1W, ±1dB / 8Ω)	20Hz~20kHz	DSP Specfication (8.24 Format)	32bit Fixed Point
A/D, D/A	24bit Conversion 　　　　　　　　　　Sampling Rate : 48kHz	DSP Function	Input Gain, Parametric EQ, HPF, LPF, Limiter, Delay

PRODUCT FEATURES

Operating Temperate 　　　　　　　　 Operating Humidity	Temperate: -10℃~+40℃ 　　　　　Humidity: 0%~90%	Power Source	AC 220-240V, 50/60Hz
Power Consumption 　　　　　　　　 (1/8 Rated Output Power@2Ω)	390W	Weight (Set)	10.48kg
Dimensions (W x H x D mm)	482(W) x 88(H) x 420(D) mm
